Micro DC brushed motor (2445)
Simple structure and easy to control
Compact size, easy to integrate
High low-speed torque
Low power consumption characteristics
Strong torque adaptability
Online Service

Motor outline drawing

Technical Specifications Table

Model Rated Voltage No load Speed No load Current Loading Moment Load Speed Load Current Stall Torque Stall Current
2445 series VDC RPM A mN.m RPM A mN.m A
18 8200 ≤1.0 10 6650±10% ≤0.9 ≥50 ≤4
