Micro DC brushed motor (2445+22 planetary series)
Simple structure and easy to control
Compact size, easy to integrate
High low-speed torque
Low power consumption characteristics
Strong torque adaptability
Online Service

Motor outline drawing

Technical Specifications Table

Model Rated Yoltage No load Speed No load Current Loading Moment Load Speed Load Current Stall Torque Ratio
2445+22 planetary series VDC RPM A mN.m RPM A mN.m
24 372 ≤0.2 100 320±10% ≤0.5 ≥700 22:1
