Automobile tail fin actuator
The core value of the tail fin actuator lies in dynamic balance control and energy efficiency: by adjusting the downforce and wind resistance in milliseconds, it balances high-speed stability and economy, while extending innovative functions such as safety warning and scene linkage. With the innovation of materials and the popularization of intelligence, its technological threshold continues to decrease, and it has become a key technology label in the performance car and modification market

Motor outline drawing

TTechnical Specifications Table

Model Voltage No Load At Maximum Efficiency Stall
Operating Range Nominal Speed Current Speed Current Torque Output Effl-Cency Torque Current
V V r/min A r/min A N.m Kg.cm W % N.m Kg.cm A
202410230601 4.5-13.5 13.5 22.5 1.3 179 6.45 0.42 4.2 7.86 9% 25 250 33
