Micro DC brushed motor (3048)
Simple structure and easy to control,
compact size, easy integration,
low speed torque,
low power consumption characteristics,
strong torque adaptability
Online Service

Motor outline drawing

Technical Specifications Table

Model Rated Yoltage No load Speed No load Current No load Current Load Speed Load Current Stall Torque Stall Current
3048 series VDC RPM A mN.m RPM A mN.m A
13.5 4650 ≤0.2 12 3820±10% ≤0.75 ≥67 ≤3
