| Model | Voltage | No Load | Performance at rated load | Stall | |||||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Output | Efficiency | Torque | Current | |||
| V | V | r/min | A | r/min | A | N.m | Kg.cm | W | N.m | Kg.cm | A | ||
| 2238N127100S+23PP63PPS158 | 8-16 | 12 | 6300~7700 | ≤3 | 3200-3800 | ≤16 | 0.15 | 1.53 | 55 | 60% | ≥0.35 | ≥3.57 | ≤30 |
* Performance can be adjusted according to customer requirements.
