| Model | Voltage | No Load | At Maximum Efficiency | Stall | |||||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Output | Effl-Cency | Torque | Current | |||
| V | V | r/min | A | r/min | A | N.m | Kg.cm | W | % | N.m | Kg.cm | A | |
| 5162BLDC-5324-A | 6-26 | 24 | 6700 | 0.33 | 5915 | 2.6 | 0.0732 | 0.732 | 44.47 | 71.25 | 0.65 | 0.65 | 20.5 |
